GAS MAD Level 2 Two Channel amplifier

GAS MAD Level 2 Two Channel amplifier

READY TO LOUD
Give up your common sense and go all MAD with the A2 series amplifiers. We made some "cool" choices in terms of ventilation, such as a custom heavy and extremely strong heat sink, while we also increased the gap between the side panels to allow air to pass unhindered under the amplifier - even in difficult mounting conditions.

LEAVE THE HATERS
Inspired by the near-perfect MAX amplifiers, we decided there was one feature we just had to include in the MAD amplifiers: the balanced differential inputs, which means less noise - and better sound. The powerful Class AB amplifier topology ensures that the A2-85.2 delivers both power and smooth sound. This is a full range amplifier, so throw everything you have at it. We support you, so go ahead and make us proud!

FOR EACH HIS OWN
What is the difference between your sound system and the rest? Well, apart from awesome amounts of power... Control, of course! We have given the MAD A2 series HPF, BPF and LPF 12 db crossovers with a wide range of functions. Build the system of your dreams, the choice is yours - but make sure it's as loud as possible!

EASY TO INSTALL SINCE 1997
You want to install this amplifier as quickly as possible and we make it easy for you to set it up. How about a CLIP function that lets you know when 1% distortion has been reached? We have also added the latest high level input technology with
ATO, automatic switching on.

SAFETY FIRST
If you are a bit nervous, things can sometimes go wrong. This is something you want to avoid at all costs, right? That is precisely why we have introduced advanced security circuits. This minimizes the risk of DC, thermal problems, overload and short circuit!

• Component: Amplifier
• Input mode: Mono / 2Ch
• Power RMS (2 Ohm): 2x125W
• Power RMS (4 Ohm): 2x85W
• Bridged Power RMS (4 Ohm): 1x250W
• Freq. Response: 15-25,000Hz
• Low Pass Filter: 50-4,000 Hz
• High Pass Filter: 15-4,000 Hz
• S/N Ratio (A-weighted): >100 dB
• Bass EQ: 0-12dB @45Hz
• Crossover Slope: 12 dB
• Power Voltage: 10-16V
• REM Voltage: 10-16V
• Input Sensitivity: 0.5-6V
• THD: <0.2%
• Power Fuse: 2x25A
• Damping Factor: >130
• High Level Input: Yes
• RCA Line Out: Yes

• 2-Channel
