GAS MAD Level 1 Two Channel amplifier

GAS MAD Level 1 Two Channel amplifier

MORE IS ALWAYS BETTER
We're always looking for the high you get from powerful bass. To keep the LOUD level high and heat low, the MAD A1-500.1D features a special lightweight A-Star heat sink chassis with a larger cooling surface area. Less material, same efficiency and great looks.

LEAVE THE HATERS
We know what it's like. You'll want to install your amplifier as soon as possible so you can show the world how loud your sound system can be. Don't worry, we've got you covered - how about a CLIP function for easy installation that helps you know when 1% distortion has been reached? We've even added a CLIP indicator to the remote for bass level, AND the latest high level input technology with ATO, auto-on. Don't mention it!

PRECISION CONTROL
What is the difference between your sound system and the rest? Check! The MAD A1-500.1D gives you LPF and subsonic 12dB crossover slopes and a 0/180 phase shift. Build the system of your dreams, the choice is yours - but make sure it's loud!

PRECISION CONTROL
If you are a bit nervous, things can sometimes go wrong. You want to prevent that, right? To ensure that your sound system
can handle, we have introduced advanced protection circuits. This minimizes the risk of direct current, thermal overload and short circuit!

• Component: Amplifier
• Channels: One
• Input mode: Mono/2CH
• Power RMS (2 Ohm): 2x105W
• Power RMS (4 Ohm): 2x70W
• Bridged Power RMS (4Ohm): 1x 220W
• Freq. Response: 15-22,000 Hz
• Low Pass Filter: 50-4000 Hz
• High Pass Filter: 50-4,000 Hz
• S/N Ratio (A-weighted): >98dB
• Bass EQ: 0-12dB @45Hz
• Crossover Slope: 12 dB
• Power Voltage: 10-16V
• REM Voltage: 10-16V
• Input Sensitivity : 0.5-6V
• THD: <0.05%
• Power Fuse: 1x35A
• Damping Factor: > 130
• RCA Line Out: Yes
• High Level Input: Yes

• 2-Channel
